Guest Post: Keeping an ear on the US Coast Guard

Photo: US Coast Guard

Many thanks to SWLing Post contributor, Jock Elliott, who shares the following guest post:


Keeping an ear on the US Coast Guard

By Jock Elliott KB2GOM

Wandering the vast expanses of YouTube, I encountered an episode of “Coast Guard Alaska” on DangerTV’s Protecting Our Waters/Coast Guard Rescue Series playlist. One episode led to another, and before long, I was binge-watching the series.

Why? Because the courage, dedication and performance of the “Coasties” is just extraordinary. They dangle from hoist cables to pluck survivors from the water, injured sailors from the decks of ships, mariners from sinking vessels, and even incapacitated hikers from mountains. They medevac sick and injured men, women, and children out of remote Alaskan villages; provide medical support while flying them to higher levels of care, and intercept drug smugglers in southern waters. I stand in awe of these men and women. (And – woe is me – it turns out there are similar series for Coast Guard Pacific Northwest and Coast Guard Florida.)

So, I wondered, could I hear the US Coast Guard on the radio? The answer, it turns out is a mixed bag.

The U.S. Coast Guard ceased monitoring all High Frequency (HF) shortwave voice distress frequencies within the contiguous United States and Hawaii on 7 February 2022.  HF voice distress watchkeeping continues unaffected in Alaska and Guam. See below for the Alaska and Guam USB frequencies.

kHz SHIP STATION kHz COAST STATION Station and Schedule (UTC)
NOJ (Kodiak AK)
4125 4125 24 HRS
6215 6215 24 HRS
8291 8291 24 HRS
12290 12290
kHz SHIP STATION kHz COAST STATION Station and Schedule (UTC)
Guam
6215 6215 0900-2100Z
12290 12290 2100-0900Z

Note: 12290 kHz is available under NOJ upon request
Note: 16420 kHz is available at NOJ and Guam upon request

So, if you have a good radio capable of upper sideband (USB) reception, a decent antenna and your location and/or propagation favors you, you might have a shot at hearing USCG Alaska or Guam HF communications.

National Weather Service Marine Products via U.S. Coast Guard HF Voice

You have a much better chance of hearing the U.S. Coast Guard broadcasting National Weather Service high seas forecasts and storm warnings from six high seas communication stations. See table below for station locations and schedules. Transmission range depends on operating frequency, time of day and atmospheric conditions and can vary from only short distances to several thousand miles.

For example, I have heard a weather forecast from the US Coast Guard Communications Command in Chesapeake, including a forecast of tropical weather from the National Hurricane Center, on 4426 USB at my home in upstate New York.

Here are the schedules:

Chesapeake (NMN)
HF Voice Broadcast Schedule

4426, 6501, 8764 kHz (USB) 0330Z1 0515Z2 0930Z1
6501, 8764, 13089 kHz (USB) 1115Z2 1530Z1 2130Z1 2315Z2
8764, 13089, 17314 kHz (USB) 1715Z2
1 Offshore Forecasts, hurricane information

2 High seas Forecast, hurricane information

Broadcast of hurricane and other weather broadcasts from this station may on occasion be preempted, as the frequencies are shared with other USCG stations.

New Orleans (NMG)
HF Voice Broadcast Schedule

4316, 8502, 12788 kHz (USB) 0330Z1 0515Z2 0930Z1 1115Z2 1530Z1 1715Z2 2130Z1 2315Z2
1 Offshore Forecasts, hurricane information

2 Highseas Forecast, hurricane information

Broadcast of hurricane and other weather broadcasts from this station may on occasion be preempted, as the transmitters are shared with the radiofax broadcast.

Pt. Reyes (NMC)
HF Voice Broadcast Schedule

4426, 8764, 13089 kHz (USB) 0430Z 1030Z
8764, 13089, 17314 kHz (USB) 1630Z 2230Z
Broadcast of hurricane and other weather broadcasts from this station may on occasion be preempted, as the frequencies are shared with other USCG stations, and the transmitters are shared with the radiofax broadcast.

Kodiak (NOJ)
HF Voice Broadcast Schedule

6501 kHz (USB) 0203Z 1645Z

Honolulu (NMO)
HF Voice Broadcast Schedule

6501, 8764 kHz (USB) 0600Z 1200Z
8764, 13089 kHz (USB) 0005Z 1800Z

Guam (NRV)
HF Voice Broadcast Schedule

6501 kHz (USB) 0930Z 1530Z
13089 kHz (USB) 0330Z 2130Z

Coastal Maritime Safety Broadcasts on VHF

The other place in the radio spectrum where you might hear voice transmissions from the Coast Guard would be on the maritime VHF channels. Urgent marine navigational and weather information is broadcast over VHF channel 22A (157.1 MHz) from over 200 sites covering the coastal areas of the U.S., including the Great Lakes, major inland waterways, Puerto Rico, Alaska, Hawaii and Guam. Broadcasts are first announced over the distress, safety and calling channel 16 (156.8 MHz) before they are made. All ships in U.S. waters over 20m in length are required to monitor VHF channel 16, and must have radios capable of tuning to the VHF simplex channel 22A.

Although VHF signals are generally short range, here at El Rancho Elliott, I can clearly hear the announcement on channel 16 on a scanner and then I can switch to channel 22A to hear the broadcast, even though my location is at least 140 miles from the nearest large body of water.  In addition, propagation sometimes opens up so that VHF signals can be heard at long distances.

Spread the radio love

Radio Waves: Friedrichshafen Cancelled, Coast Guard Seeks Rare Diode, Kindred Spirits in DXing, and DRM Pitch for India’s FM Band

Radio Waves:  Stories Making Waves in the World of Radio

Because I keep my ear to the waves, as well as receive many tips from others who do the same, I find myself privy to radio-related stories that might interest SWLing Post readers.  To that end: Welcome to the SWLing Post’s Radio Waves, a collection of links to interesting stories making waves in the world of radio. Enjoy!

Many thanks to SWLing Post contributors Dennis Dura, Ron Chester, and Mangosman for the following tips:


Ham Radio Verbindung 2021 kommt nicht zustande/Ham Radio convention 2021 has been cancelled (Messe Friedrichshafen)

[Note that the following is a Google translation of the original piece in German]

Ham Radio cannot take place this year either – other trade fair events remain on course

Due to the current corona developments, Messe Friedrichshafen cannot hold the international amateur radio exhibition Ham Radio in the planned period from June 25 to 27, 2021. Instead, the industry meeting will take place from June 24 to 26, 2022.

“The decision was not an easy one for us, but a trade fair like Ham Radio lives from its high level of internationality. Due to the current uncertainties in the travel sector, implementation is currently not feasible, ”explains Klaus Wellmann, Managing Director of Messe Friedrichshafen. All other trade fair events in the second quarter of 2021 and beyond should take place as planned at the present time. “A large percentage of our customers from these industries are still on board at the 2021 events. Together we hope that the immunization of society continues to gain momentum and that we can carry out the events with appropriate protection and hygiene concepts. “

Further information at: www.messe-friedrichshafen.de and http://www.hamradio-friedrichshafen.de/.

Rare Diode Threatens Coast Guard’s Arctic Ambitions (Hackaday)

The United States Coast Guard heavy icebreaker Polar Star is literally a one-of-a-kind ship. After its sister Polar Sea was deactivated in 2010 it became the most powerful icebreaker in the fleet, and one of only two US icebreakers capable of operating in the treacherous polar regions. The vessel is critical to protecting America’s scientific and economic interests in the Arctic, but according to a recent article in Business Insider, the ship’s age and scarcity of spare parts is making an already difficult mission even harder.

In the article, Captain William Woityra specifically mentions that the ship’s diesel-electric propulsion system is running on borrowed time as the diodes used in its AC/DC rectifier are no longer manufactured. With none remaining in the Coast Guard’s inventory, the crew has had to turn to eBay to source as many spares as possible. But once their hoard runs out, Captain Woityra fears his ship will be dead in the water[]

A toast to the fools standing high on broadcasting’s hill (Doc Searls Weblog)

In Winter, the cap of dark on half the Earth is cocked to the north. So, as the planet spins, places farther north get more night in the winter. In McGrath, Alaska, at close to sixty-three degrees north, most of the day is dark. This would be discouraging to most people, but to Paul B. Walker it’s a blessing. Because Paul is a DXer.

In the radio world, DX stands for for distance, and DXing is listening to distant radio stations. Thanks to that darkness, Paul listens to AM stations of all sizes, from Turkey to Tennessee, Thailand to Norway. And last night, New Zealand. Specifically, NewsTalk ZB‘s main AM signal at 1035 on the AM (what used to be the) dial. According to distancecalculator.net, the signal traveled 11886.34 km, or 7385.83 miles, across the face of the earth. In fact it flew much farther, since the signal needed to bounce up and down off the E layer of the ionosphere and the surface of the ocean multiple times between Wellington and McGrath. While that distance is no big deal on shortwave (which bounces off a higher layer) and no deal at all on the Internet (where we are all zero distance apart), for a DXer that’s like hauling in a fish the size of a boat.

In this sense alone, Paul and I are kindred souls. As a boy and a young man, I was a devout DXer too. I logged thousands of AM and FM stations, from my homes in New Jersey and North Carolina. (Here is a collection of QSL cards I got from stations to which I reported reception, in 1963, when I was a sophomore in high school.) More importantly, learning about all these distant stations sparked my interest in geography, electronics, geology, weather, astronomy, history and other adjacent fields. By the time I was a teen, I could draw all the states of the country, freehand, and name their capitals too. And that was on top of knowing on sight the likely purpose of every broadcast tower and antenna I saw.[]

DRM Makes Its Pitch for India’s FM Band (Radio World)

In India, where regulators have been working toward recommending a standard to digitize the FM band, Digital Radio Mondiale is presenting its case.

DRM has been conducting trials and demos since late February, when a digital radio transmission with three audio services and Journaline text information went live in Delhi alongside existing analog FM transmissions.

It said it is also showing the possibility of extending a shared transmitter infrastructure by broadcasting up to six individual DRM signals or blocks, carrying up to 18 audio services plus 6 multimedia services, being broadcast from one FM transmitter and antenna. It said the number of individual DRM signals is only limited by the bandwidth of the transmitter. Each signal can have its own power level, and gaps in the spectrum are possible, as are individual SFN networks per DRM signal.

“The transmission is part of an extensive trial and demonstration of DRM conducted by Prasar Bharati and its radio arm, All India Radio (AIR), with the help of the DRM Consortium and its local and international members,” DRM stated in a press release. “The test was officially launched on Feb. 24 and 25 at the headquarters of All India Radio in New Delhi.”

The test was requested by regulator TRAI and the Ministry of Information & Broadcasting.

DRM officials said a presentation to AIR’s committee showed DRM in the FM band on various car radios including line-fit, aftermarket, standalone receivers, mobile phones and tablets. A head unit from Mobis, upgraded for FM via firmware, was installed in a Hyundai Verna. DRM said, “The reception was found to be excellent for over 15 km radius with just 100 W of DRM power in digital,” including 5.1 surround sound test broadcasts on DRM.[]

You might also check out the article HD Radio and Digital FM in India at Radio World.
