Chameleon Antenna recently sent me a prototype of their latest antenna: the CHA MPAS Lite.
The MPAS Lite is a compact version of their MPAS 2.0 modular antenna system and designed to be even more portable.
Chameleon Antenna is a specialist antenna manufacturer that makes military-grade, field portable antennas that are low-profile and stealthy. Chameleon products are 100% made in the USA and their customers range from amateur radio operators to the armed forces.
Their antennas are not cheap, but they are a prime example when we talk about “you pay for what you get.” In all of my years of evaluating radio products, I’ve never seen better quality field antennas–they’re absolutely top-shelf.
I’m currently in my hometown doing a little caregiving for my parents. I’d only planned to be here for a couple of days, but when I saw that the remnants of Hurricane Zeta would pass directly over us with tropical storm force winds and rain, I stuck around to help the folks out.
Zeta struck quite a blow, in fact. No injuries reported, but over 23,000 of us have been without power for over 34+ hours in Catawba county. With saturated grounds, the winds toppled a lot of trees and damaged power lines.
Yesterday, I wanted to take advantage of the power outage and get on the air. I couldn’t really do a POTA activation because I needed to manage things here at my parents’ house. Plus, why not profit from the grid being down and bathe in a noise-free RF space–?
I decided to set it up in their front yard.
CHA MPAS Lite
I had never deployed the MPAS Lite before, so I did a quick scan through the owner’s manual. Although the MPAS Lite (like the MPAS 2.0) can be configured a number of ways, I deployed it as a simple vertical antenna.
Assembly was simple:
Insert the stainless steel spike in the ground,
Attach the counterpoise wire (I unraveled about 25′) to the spike
Screw on the CHA Micro-Hybrid
Screw the 17′ telescoping whip onto the Hybrid-Micro
Extend the whip antenna fully
Connect the supplied coax (with in-line choke) to the Hybrid-Micro
Connect the antenna to the rig
Although I had the Icom IC-705 packed, I wanted to keep things simple by using the Elecraft KX2 I’d also packed since it has a built-in ATU.
Important: the CHA MPAS Lite requires an ATU to get a good match across the bands.
I wasn’t in the mood to ragchew yesterday, but I thought it might be fun to see how easily I could tune the MPAS Lite from 80 meters up.
I checked the Parks On The Air spots page and saw NK8O activating a park in Minnesota in CW:
He was working a bit of a pile-up, but after three calls, he worked me and reported a 559 signal report. Not bad at 5 watts!
I then moved to 40, 18, and 20 meter and called CQ a couple times to see if the Reverse Beacon Network (RBN) could spot me. I like using the RBN to give me a “quick and dirty” signal report. I was very pleased with the bands I tested:
Those dB numbers are quite good for an op running 5 watts into a vertical compromised antenna.
The KX2 very effortlessly got near 1:1 matches on every band I tested.
Of course, after working a few stations in CW and SSB, I tuned to the broadcast bands and enjoyed a little RFI-free SWLing. Noting 13dka’s recent article, I’m thinking on the coast, the MPAS Lite will make for a superb amateur radio and SWLing antenna.
Although the remnants of Zeta had effectively passed through the area three hours prior, it was still very blustery outside. I was concerned gusts might even be a little too strong for the 17′ whip, but I was wrong. The whip handled the wind gusts with ease and the spike held it in place with no problem.
One of the things I have to watch with my Wolf River Coils TIA vertical is the fact it’s prone to fall in windy conditions and many ops have noted that this can permanently damage the telescoping whip (the weak point in that system).
I’m pretty certain this wouldn’t happen with the Chameleon 17′ whip–it feels very substantial and solid.
Ready to hit the field with the CHA MPAS Lite!
I’m a huge fan of wire antennas because I believe they give me the most “bang-for-buck” in the field, but they’re not always practical to deploy. I like having a good self-supporting antenna option in my tool belt when there are no trees around or when parks don’t allow me to hang antennas in their trees.
I’ve got a park in mind that will make for a good test of the CHA MPAS Lite: it’s a remote game land with no real parking option. I’ll have to activate it on the roadside–an ideal application for the MPAS Lite.
I just discovered Rob Sherwood (NC0B) will be on Ham Talk Live tonight. Rob always has fascinating comments about receiver performance, so this should be a great episode.
Here are details:
Rob Sherwood, NC0B from Sherwood Engineering returns to Ham Talk Live! Thursday night to talk about the performance of several radios since his last visit on this show and will take your questions live about his analysis.
Tune into Ham Talk Live! Thursday night at 9 pm EDT (Friday 0100Z) by going to hamtalklive.com. When the audio player indicates LIVE, just hit the play button!
If you miss the show live, you can listen on demand anytime also at hamtalklive.com;
or a podcast version is on nearly all podcast sites a few minutes after the live show is over. Some sites include Apple Podcasts, Stitcher, Google Play, SoundCloud, and iHeart Podcasts; and it’s also available on YouTube. A replay is also broadcast on WTWW 5085 AM on Saturday nights at approximately 3:30 pm Eastern.
Be sure to CALL in with your questions and comments by calling 859-982-7373 live during the call-in segment of the show. You can also tweet your questions before or during the show to @HamTalkLive.
Thursdays at 9 pm Eastern (Friday 0100Z Mar-Nov / 0200Z Nov-Mar) Live call-in talk radio show about Amateur (Ham) Radio – Hosted by Neil Rapp, WB9VPG Call 859-982-7373 to join the conversation!
Many thanks to SWLing Post contributor, Jim Meirose, who recently shared the following listener post:
Listener Post by Jim Meirose
My interest in radio started around 1960-61. My uncle was going to take a giant worn-out console Record Player/AM/FM/SW 1940s monstrosity to the dump. My father, who was an electrician and a general nut for all things electrical, stopped him, took the radio out before the console got trashed, put it in a makeshift cabinet, and showed me how to use it. That was how I got started.
A neat thing about the radio was it had one of those old “magic eye” tubes to aid in tuning. What could be cooler for a kid to play with? Plus, being able to hear all of what was to me just “weird stuff” on shortwave, was what got me hooked.
After a year or two I got the Heathkit GR-91 as a gift and my father helped me assemble it. We also put up a better antenna.
My Heathkit GR-91 and Q-mult I used starting in 1963, with a variety of antennas, up to 1971. (Stored in the cellar now, as you can see)
I spent several years and many many hours listening and logging and having fun with it. We were at or near the peak of the sunspot cycle then, so as you can imagine, it was amazing. That made it a pretty “hot” radio (although in that decade the high sunspots made most every radio “hot”) but it had one flaw that was really bad. The tuning dial was not even close to accurate. I even had it professionally aligned, in vain. You only had a ballpark idea of what frequency you were on.
The next problem with the GR-91 was that as you tuned up past around 14 MHz, a hum began and grew to where there was no point trying to listen at all for anything all the way up to 30 MHz. I gradually became most interested in 20 meter amateur radio listening.
I learned to tune SSB, helped by the fact that the set had a good BFO and great bandspread tuning. From about 1964 to 1968, I heard hams from over 250 ARRL countries. These were mostly on 20 meters, using a dipole. Then, I got drafted to the Army until 1970, came back, and listened again until about 1972. Then, life took over, and the radio was put away.
Around 2004, I started getting interested again. I got an old Hammarlund HQ-180, thinking to pick up where I left off in ’72, but gave up when I found the sunspot cycle was bottomed out. Plus, the old set was too complicated and difficult to use, and not in the best shape. So, again, radio was put aside.
Finally, early this year, having the time at last to do things right, after shopping around, I got the Kenwood R-600, put up a good antenna, and started in. Once I got in the groove again, I found the R-600 to be incredible. The reception is crystal-clear across all bands. Plus, lo and behold, with the digital dial I know EXACTLY what frequency I am on! And as far as DX, even with today’s low sunspots, I am hearing the whole world, better than in the 60s. Might not be “booming in” as they say, but still very cool. The key is to know when, where, and how to listen.
Lastly, besides the better technology of the radio, imagine the difference between now and the ‘60s, when there was no internet, no computers, and practically no reliable hard copy directories to be found. At least with ham radio listening, it was easy to ID what country was on, because of the standardized call sign prefixes. But, for broadcast stations, the only real way to identify the more “exotic” non-english language stations, was by listening, sometimes for hours, hoping to catch some recognizable station ID. More often than not, this would never come before the station went off-air, or faded out. Today, with online directories, that is not such a problem. But, imagine how, with my GR-91, being unable to provide exact frequency readings, that even the modern online directories would have been practically useless.
That’s it, there are the highlights of my shortwave experience from 1960 to today. Hope it was of interest.
The seller, who lives about 2 hours from my QTH, described his KX1 as the full package: a complete 3 band (40/30/20M) KX1 with all of the items needed to get on the air (save batteries) in a Pelican 1060 Micro Case.
The KX1 I owned in the past was a four bander (80/40/30/20M) and I already double checked to make sure Elecraft still had a few of their 80/30 module kits available (they do!). I do operate 80M in the field on occasion, but I really wanted the 80/30 module to get full use of the expanded HF receiver range which allows me to zero-beat broadcast stations and do a little SWLing while in the field.
The seller shipped the radio that same afternoon and I purchased it for $300 (plus shipping) based purely on his good word.
The KX1 package
I’ll admit, I was a bit nervous: I hadn’t asked all of the typical questions about dents/dings, if it smelled of cigarette smoke, and hadn’t even asked for photos. I just had a feeling it would all be good (but please, never follow my example here–I was drunk with excitement).
Here’s the photo I took after removing the Pelican case from the shipping box and opening it for the first time:
My jaw dropped.
The seller was right: everything I needed (and more!) was in the Pelican case with the KX1. Not only that, everything was labeled. An indication that the previous owner took pride in this little radio.
I don’t think the seller actually put this kit together. He bought it this way two years ago and I don’t think he ever even put it on the air based on his note to me. He sold the KX1 because he wasn’t using it.
I don’t know who the original owner was, but they did a fabulous job not only putting this field kit together, but also soldering/building the KX1. I hope the original owner reads this article sometime and steps forward.
You might note in the photo that there’s even a quick reference sheet, Morse Code reference sheet and QRP calling frequencies list attached to the Pelican’s lid inside. How clever!
I plan to replace the Morse Code sheet with a list of POTA and SOTA park/summit references and re-print the QRP calling frequencies sheet. But other than that, I’m leaving it all as-is. This might be the only time I’ve ever purchased a “package” transceiver and not modified it in some significant way.
Speaking of modifying: that 80/30 meter module? Glad I didn’t purchase one.
After putting the KX1 on a dummy load, I checked each band for output power. Band changes are made on the KX1 by pressing the “Band” button which cycles through the bands one-way. It started on 40 meters, then on to 30 meters, and 20 meters. All tested fine. Then I pressed the band button to return to 40 meters and the KX1 dived down to the 80 meter band!
Turns out, this is a four band KX1! Woo hoo! That saved me from having to purchase the $90 30/80M kit (although admittedly, I was looking forward to building it).
The only issue with the KX1 was that its paddles would only send “dit dah” from either side. I was able to fix this, though, by disassembling the paddles and fixing a short.
Although I’m currently in the process of testing the Icom IC-705, I’ve taken the KX1 along on a number of my park adventures and switched it out during band changes.
Indeed, my first two contacts were made using some nearly-depleted AA rechargeables on 30 meters: I worked a station in Iowa and one in Kansas with perhaps 1.5 watts of output power–not bad from North Carolina!
I’m super pleased to have the KX1 back in my field radio arsenal.
I name radios I plan to keep for the long-haul, so I dubbed this little KX1 “Ruby” after one of my favorite actresses, Barbara Stanwyck.
Look for Ruby and me on the air at a park or summit near you!
Many thanks to SWLing Post contributor, 13dka, who shares the following guest post:
Gone fishing…for DX: Reception enhancement at the seaside
In each of my few reviews I referred to “the dike” or “my happy place”, which is a tiny stretch of the 380 miles of dike protecting Germany’s North Sea coast. This is the place where I like to go for maximum listening pleasure and of course for testing radios. Everyone knows that close proximity to an ocean is good for radio reception…but why is that? Is there a way to quantify “good”?
Of course there is, this has been documented before, there is probably lots of literature about it and old papers like this one (click here to download PDF). A complete answer to the question has at least two parts:
1. Less QRM
It may be obvious, but civilization and therefore QRM sources at such a place extend to one hemisphere only, because the other one is covered with ocean for 100s, if not 1000s of miles. There are few places on the planet that offer such a lack of civilization in such a big area, while still being accessible, habitable and in range for pizza delivery. Unless you’re in the midst of a noisy tourist trap town, QRM will be low. Still, you may have to find a good spot away from all tourist attractions and industry for absolutely minimal QRM.
My dike listening post is far enough from the next small tourist trap town (in which I live) and also sufficiently far away from the few houses of the next tiny village and it’s located in an area that doesn’t have HV power lines (important for MW and LW reception!) or industrial areas, other small villages are miles away and miles apart, the next town is 20 km/12 miles away from there. In other words, man-made noise is just not an issue there.
That alone would be making shortwave reception as good as it gets and it gives me an opportunity to check out radios on my own terms: The only way to assess a radio’s properties and qualities without or beyond test equipment is under ideal conditions, particularly for everything that has to do with sensitivity. It’s already difficult without QRM (because natural noise (QRN) can easily be higher than the receiver’s sensitivity threshold too, depending on a number of factors), and even small amounts of QRM on top make that assessment increasingly impossible. This is particularly true for portables, which often can’t be fully isolated from local noise sources for a couple of reasons.
Yes, most modern radios are all very sensitive and equal to the degree that it doesn’t make a difference in 98% of all regular reception scenarios but my experience at the dike is that there are still differences, and the difference between my least sensitive and my most sensitive portable is not at all negligible, even more because they are not only receivers but the entire receiving system including the antenna. You won’t notice that difference in the middle of a city, but you may notice it in the woods.
When the radio gets boring, I can still have fun with the swing and the slide!
2. More signal
I always had a feeling that signals actually increase at the dike and that made me curious enough to actually test this by having a receiver tuned to some station in the car, then driving away from the dike and back. Until recently it didn’t come to me to document or even quantify this difference though. When I was once again googling for simple answers to the question what the reason might be, I stumbled upon this video: Callum (M0MCX) demonstrating the true reason for this in MMANA (an antenna modeling software) on his “DX Commander” channel:
To summarize this, Callum explains how a pretty dramatic difference in ground conductivity near the sea (click here to download PDF) leads to an increase in antenna gain, or more precisely a decrease in ground return losses equaling more antenna gain. Of course I assumed that the salt water has something to do with but I had no idea how much: For example, average ground has a conductivity of 0.005 Siemens per meter, salt water is averaging at 5.0 S/m, that’s a factor of 1,000 (!) and that leads to roughly 10dB of gain. That’s right, whatever antenna you use at home in the backcountry would get a free 10dB gain increase by the sea, antennas with actual dBd or dBi gain have even more gain there.
That this has a nice impact on your transmitting signal should be obvious if you’re a ham, if not just imagine that you’d need a 10x more powerful amplifier or an array of wires or verticals or a full-size Yagi to get that kind of gain by directionality. But this is also great for reception: You may argue that 10dB is “only” little more than 1.5 S-units but 1.5 S-units at the bottom of the meter scale spans the entire range between “can’t hear a thing” and “fully copy”!
A practical test
It’s not that I don’t believe DX Commander’s assessment there but I just had to see it myself and find a way to share that with you. A difficulty was finding a station that has A) a stable signal but is B) not really local, C) on shortwave, D) always on air and E) propagation must be across water or at least along the shoreline.
The army (or navy) to the rescue! After several days of observing STANAG stations for their variation in signal on different times of the day, I picked one on 4083 kHz (thanks to whoever pays taxes to keep that thing blasting the band day and night!). I don’t know where exactly (my KiwiSDR-assisted guess is the English channel region) that station is, but it’s always in the same narrow range of levels around S9 here at home, there’s usually the same little QSB on the signal, and the signals are the same day or night.
On top of that, I had a look at geological maps of my part of the country to find out how far I should drive into the backcountry to find conditions that are really different from the coast. Where I live, former sea ground and marsh land is forming a pretty wide strip of moist, fertile soil with above average conductivity, but approximately 20km/12mi to the east the ground changes to a composition typical for the terminal moraine inland formed in the ice age. So I picked a quiet place 25km east of my QTH to measure the level of that STANAG station and also to record the BBC on 198 kHz. Some source stated that the coastal enhancement effect can be observed within 10 lambda distance to the shoreline, that would be 730m for the 4 MHz STANAG station and 15km for the BBC, so 25km should suffice to rule out any residue enhancement from the seaside.
My car stereo has no S-meter (or a proper antenna, so reception is needlessly bad but this is good in this case) so all you get is the difference in audio. The car had the same orientation (nose pointing to the east) at both places. For the 4 MHz signal though (coincidence or not), the meter shows ~10dBm (or dBµV/EMF) more signal at the dike.
3. Effect on SNR
Remember, more signal alone does not equal better reception, what we’re looking for is a better signal-to-noise ratio (SNR). Now that we’ve established that the man-made noise should be as low as possible at “my” dike, the remaining question is: Does this signal enhancement have an effect on SNR as well? Even if there is virtually no local QRM at my “happy place” – there is still natural noise (QRN) and that wouldn’t that likely gain 10dB too?
Here are some hypotheses that may be subject of debate and some calculations way over my head (physics/math fans, please comment and help someone out who always got an F in math!). Sorry for all the gross oversimplifications:
Extremely lossy antennas
We know that pure reception antennas are often a bit different in that the general reciprocity rule has comparatively little meaning, many antennas designed for optimizing reception in specific situations would be terrible transmitting antennas. One quite extreme example, not meant to optimize anything but portability is the telescopic whip on shortwaves >10m. At the dike, those gain more signal too. When the QRN drops after sunset on higher frequencies, the extremely lossy whip might be an exception because the signal coming out of it is so small that it’s much closer to the receiver noise, so this friendly signal boost could lift very faint signals above the receiver noise more than the QRN, which in turn could mean a little increase in SNR, and as we know even a little increase in SNR can go a long way.
The BBC Radio 4 longwave recording is likely another example for this – the unusually weak signal is coming from a small and badly matched rubber antenna with abysmal performance on all frequency ranges including LW. The SNR is obviously increasing at the dike because the signal gets lifted more above the base noise of the receiving system, while the atmospheric noise component is likely still far below that threshold. Many deliberately lossy antenna design, such as flag/tennant, passive small aperture loops (like e.g. the YouLoop) or loop-on-ground antennas may benefit most from losses decreasing by 10dB.
Not so lossy antennas, polarization and elevation patterns
However, there is still more than a signal strength difference between “big” antennas and the whips at the dike: Not only at the sea, directionality will have an impact on QRN levels, a bidirectional antenna may already decrease QRN and hence increase SNR further, an unidirectional antenna even more, that’s one reason why proper Beverage antennas for example work wonders particularly on noisy low frequencies at night (but this is actually a bad example because Beverage antennas are said to work best on lossy ground).
Also, directional or not, the “ideal” ground will likely change the radiation pattern, namely the elevation angles, putting the “focus” of the antenna from near to far – or vice versa: As far as my research went, antennas with horizontal polarization are not ideal in this regard as they benefit much less from the “mirror effect” and a relatively low antenna height may be more disadvantageous for DX (but maybe good for NVIS/local ragchewing) than usual. Well, that explains why I never got particularly good results with horizontal dipoles at the dike!
Using a loop-on-ground antenna at a place without QRM may sound ridiculously out of place at first, but they are bidirectional and vertically polarized antennas, so the high ground conductivity theoretically flattens the take-off angle of the lobes, on top of that they are ~10dB less lossy at the dike, making even a LoG act more like something you’d string up as high as possible elsewhere. They are incredibly convenient, particularly on beaches where natural antenna supports may be non-existent and I found them working extremely well at the dike, now I think I know why. In particular the preamplified version I tried proved to be good enough to receive 4 continents on 20m and a 5th one on 40m – over the course of 4 hours on an evening when conditions were at best slightly above average. Though the really important point is that it increased the SNR further, despite the QRN still showing up on the little Belka’s meter when I connected the whip for comparison (alas not shown in the video).
The 5th continent is missing in this video because the signals from South Africa were not great anymore that late in the evening, but a recording exists.
Here’s a video I shot last year, comparing the same LoG with the whip on my Tecsun S-8800 on 25m (Radio Marti 11930 kHz):
At the same time, I recorded the station with the next decent KiwiSDR in my area:
Of course, these directionality vs noise mechanisms are basically the same on any soil. But compensating ground losses and getting flat elevation patterns may require great efforts, like extensive radial systems, buried meshes etc. and it’s pretty hard to cover enough area around the antenna (minimum 1/2 wavelength, ideally more!) to get optimum results on disadvantaged soils, while still never reaching the beach conditions. You may have to invest a lot of labor and/or money to overcome such geological hardships, while the beach gives you all that for free.
But there may be yet another contributing factor: The gain pattern is likely not symmetrical – signals (and QRN) coming from the land side will likely not benefit the same way from the enhancement, which tapers off quickly (10 wavelengths) on the land side of the dike and regular “cross-country” conditions take place in that direction, while salt water stretching far beyond the horizon is enhancing reception to the other side.
So my preliminary answer to that question would be: “Yes, under circumstances the shoreline signal increase and ground properties can improve SNR further, that improvement can be harvested easily with vertically polarized antennas”.
Would it be worthwhile driving 1000 miles to the next ocean beach… for SWLing?
Maybe not every week–? Seriously, it depends.
Sure, an ocean shoreline will generally help turning up the very best your radios and antennas can deliver, I think the only way to top this would be adding a sensible amount of elevation, a.k.a. cliff coasts.
If you’re interested in extreme DX or just in the technical performance aspect, if you want to experience what your stuff is capable of or if you don’t want to put a lot of effort into setting up antennas, you should definitely find a quiet place at the ocean, particularly if your options to get maximum performance are rather limited (space constraints, QRM, HOA restrictions, you name it) at home.
If you’re a BCL/program listener and more interested in the “content” than the way it came to you, if you’re generally happy with reception of your favorite programs or if you simply have some very well working setup at home, there’s likely not much the beach could offer you in terms of radio. But the seaside has much more to offer than fatter shortwaves of course.
From left to right: Starry sky capture with cellphone cam, nocticlucent clouds behind the dike, car with hot coffee inside and a shortwave portable suction-cupped to the side window – nights at the dike are usually cold but sometimes just beautiful. (Click to enlarge.)
However, getting away from the QRM means everything for a better SNR and best reception. In other words, if the next ocean is really a hassle to reach, it may be a better idea to just find a very quiet place nearby and maybe putting up some more substantial antenna than driving 1000 miles. But if you happen to plan on some seaside vacation, make absolutely sure you bring two radios (because it may break your heart if your only radio fails)!
Hello Readers! This Saturday (10/24) there will be two special broadcasts of VORW Radio International targeting listeners in Europe and North America. They will be broadcast from WWCR in Nashville, Tennessee with a power of 100 kW each.
Each broadcast will be 1 Hour in length and will feature music (1960s – Present) and commentary, overall I hope for it to be an enjoyable show!
Here is the broadcast schedule:
Saturday October 24th at 1100 UTC (7 AM Eastern / 1 PM CEST) – 15825 kHz – WWCR 100 kW – To Europe & Eastern North America
Saturday October 24th at 1900 UTC (3 PM Eastern / 9 PM CEST) – 13845 kHz – WWCR 100 kW – To Europe & North America
Reception reports may be sent to firstname.lastname@example.org
Many thanks to SWLing Post contributor, Ed, who writes:
SWLing Post readers might be interested in learning that KTWR in Guam
has announced new DRM transmission details including a new DXer’s
Program named “Love Asia By Radio” which is scheduled to first air on
October 25, 2020 on their 1026-1057UTC English DRM broadcast to India
on 13800kHz. I just posted a question on their blog asking if the
program audio will be made available online to potential listeners
who can’t receive the broadcast, but haven’t heard back from them
yet. If I do, I’ll share that info.
KTWR New DRM Transmission Details and DXer Programme
People have asked us to air a DX program for many years. KTWR had
done this a few decades ago, but we had no one to produce a new
program. Now, one of our listeners, Arun Kumar Narasimham has begun
production of the “Dxers Diary”. The first airing will be on 25
October 2020 in our 1026-1057UTC English DRM broadcast to India on
13800kHz. We are glad that Arun has stepped in to fill this
longstanding gap in our programming. We hope you enjoy it and
continue to enjoy the DX hobby.
Thank you for the tip, Ed, and we’ll look forward to any updates you might have.
