Simple Wire Antenna: Giuseppe’s Mediumwave DXing Adventures from the Tyrrhenian Sea

16 Replies

Many thanks to SWLing Post contributor, Giuseppe Morlè (IZ0GZW), who writes:

Dear Thomas and Friends of SWLing Post,

I am Giuseppe Morlè from Formia, Central Italy, on the Tyrrhenian Sea.

This time, I want to share a very simple antenna setup for listening to and attempting extreme DX on Medium Waves.

I first saw this antenna in several videos, and many DXers have used it during various expeditions.

For my setup, I used a 15-meter-long wire. At around 11 meters, I formed a small coil with 8 turns, then continued the wire for another 3 meters.

I began with some tests on my balcony by laying the wire flat along the ground for its entire length. I used my small Sony SRF-37V as a receiver. By placing the receiver within the coil of turns, I immediately noticed a significant difference compared to the built-in ferrite antenna.

In the early afternoon, I tuned into a Chinese language broadcast on 1377 kHz. You can watch a video of this experiment on my YouTube channel:

Encouraged by the excellent results, I decided to head to the tourist port of Caposele di Formia the next day in the early afternoon. I set up on the pier overlooking the sea. This time, I laid the wire in an eastward direction — towards the night, where the sun had already set, while it was still high for another two hours on my side.

Once again, I achieved amazing results.

I was able to hear the same Chinese station on 1377 kHz, but this time with much clearer audio than from my balcony, where electrical noise interfered. By the sea, the signal was clean and strong.

After a while, I tuned into VOA broadcasts from Thailand on 1575 and 1395 kHz, both with surprisingly good audio quality. You can see this second experiment here:

Sometimes, all it takes is a bit of wire and a small coil to create an excellent, ground-level antenna — in this case, oriented eastward.

I also tried using my loop cassette and a Tecsun PL-660 but couldn’t hear anything. Yet the little Sony SRF-37V proved itself to be a true “DX killer” on AM — truly impressive.

I even caught a segment of the VOA program “World Today,” discussing the Chinese economy and Southeast Asia.

As the sun set, the DX signals faded, making way for closer European and Asian broadcasters.

I will definitely return with a longer wire to see if this surprising setup can be improved even more.

A warm greeting to all the Friends who follow SWLing Post and to you, Dear Thomas.

73, Giuseppe IZ0GZW

More Reception Videos:

Spread the radio love

Bob’s Radio Corner: Pairing a Phone or Tablet with a Radio

9 Replies

Pairing a Phone or Tablet with a Radio

By Bob Colegrove

The Internet is full of resources for radio listeners and hobbyists.  There are numerous examples of general information, frequency, and schedule lists.  There are also WebSDR sites, which allow you to compare reception experiences from around the world.  All of these can be accessed quickly and easily by having them loaded on your phone or tablet operating side-by-side with your radio and having Wi-Fi or cellular access.  We never had any of this when I was starting out.

I realize there are other ways to go about what I have described below, for example, merging station listings with SDR.  This posting is for folks like me who are SDR-challenged.  I listen to plain old radios.  My modern-day experience with newfangled technology has been limited to hitchhiking on WebSDR sites for the last few years.  It has served me well.

Ideally, I would like to generalize this topic to simply cover all phones and tablets.  In truth, my experience has been limited to an iPhone and Kindle Fire tablets.  They have worked very well as I shall explain.  Perhaps you have paired a different phone or tablet with your radio, in which case, feel free to share your experience.

The choice of a phone or tablet is yours.  Either works well.  Your decision will be affected by what you have available and what is easier to use.  If you intend to buy a new device and associate it with your radio, cost will be an additional factor.

A noteworthy device (the one I tend to favor) is a Kindle Fire.  Mainly, they are cheap.  The regular price of a 7-inch model is just under $60 and can often be purchased for less during Black Friday and Prime Day sales.  It is versatile, possessing all the usual functions except for cellular access.  Perhaps most importantly, it is virtually noise-free.  For a while I struggled using Internet sources on a laptop computer.  Even a good one located about 10 feet away from the radio antenna generates noise.  On the other hand, I have taken a 7-inch Kindle Fire in hand and placed it against the resonant coil of a loop antenna.  This abuse generated no more disturbance to the antenna than if it were a block of pinewood.  I have noticed some slight noise from the 11” Kindle when the antenna is exposed this way, but when that tablet is held at arm’s length from the antenna, all is well.  Recently, I have expanded this application to my iPhone and found its noise immunity matches that of the Kindle Fire 7.

Broadcast Schedules

The most useful Internet resources are the broadcast schedules.  These are the comprehensive frequency-time-station listings that tell us where and when to tune.  There are many good ones.  My favorites are the EiBi listing http://www.eibispace.de/, and Dan Ferguson’s https://groups.io/g/swskeds/topics.  For the latter you will need to request membership.  SWskeds merges EiBi, Aoki (https://www1.s2.starcat.ne.jp/ndxc), HFCC (https://new.hfcc.org/index.php), as well as other sources into a single list.

Processing

The EiBi listing comes as a CSV-formatted text file, which can be imported into a spreadsheet. I have done some processing using spreadsheet functions to produce a customized listing.  Processing the frequency-time-station lists is most conveniently done using a computer rather than the phone or tablet.   Processing includes selecting, arranging, or filtering the downloaded data tailored to your needs.  This might include adding a filterable column to indicate only stations that are on at the current time.  Some users might favor filtering by country or station. The heavy lifting processing is done automatically whenever a new listing is published by simply dropping the new file into the existing spreadsheet.  No, the functionality of a spreadsheet and ease of editing are not as good on a tablet as with the mouse and keyboard of a computer.  My processing on the computer includes measures to optimized the screen view to the most essential information thus minimizing the amount of scrolling on the tablet.

After the files are downloaded and processed, they can be loaded on the phone or tablet in a couple of different ways.  They can be directly transferred over a USB cable, or they can be transferred using a cloud server.  The USB cable-transfer method may be difficult on some devices, particularly iPhones.  The Kindle seems to be the more convenient device.  Being an obedient Microsoft customer, I can also transfer the files from my computer to OneDrive, then pick them up on the Kindle or iPhone using the OneDrive and Microsoft 365 apps which are available for both phone and tablet.

Examples

The screenshot below shows an EiBi example at 0014 UTC.  Although the “ON” column filter is set to show only transmissions currently “ON,” it had not been manually updated on the Kindle for a couple hours and thus includes listings from a previous time.  The EiBi database does not include transmitter power or beam information.  However, the identification of countries and transmitter sites is extensive.  These are determined by downloading and printing the README.TXT file on the EiBi site.

The SWSkeds listing is available in both CSV and Excel formats.  It contains several additional data fields, very importantly including transmitter power and beam direction when available.  For this list, I make the simple conversion of the existing Excel data range tab, “COMBINED” to a table so I can easily apply filters.  The screenshot below shows an example at 1750 UTC with the “ON” column filtered to “ON.”

Not to be left out, the complete medium wave broadcast station list for Region 2, the Americas, is easily downloadable at https://www.fcc.gov/media/radio/am-query.  The entire database is formidable and contains nearly 600 pages in a printable format.  Much of this bulk is due to the doubled size necessitated by giving both daytime and nighttime power separate entries for each station.  A number of marginally useful data columns can be eliminated in spreadsheet processing.  I have added formulas to calculate the azimuth heading and distance from my listening post (blanked out in the example below).

A variation of the downloadable file format is the direct-query site, SHORT.WAVE.INFO.  Here you can simply enter queries by station, language, frequency, or band, and produce listings which match your criteria.  Any listings which are currently on the air will be highlighted in red.

WebSDR

Finally, I would like to mention the WebSDR sites.  While not used explicitly for broadcast schedules, these sites are great for anyone wanting to compare how well they are receiving signals relative to what others are experiencing.  Granted, location and time of day are big factors that affect reception, but it is still useful to make these relative comparisons.

Home base is http://websdr.org/ which presents a catalog of many WebSDR sites by location.  At the bottom of the page is a world map which pinpoints the location of each site.  Most of these sites cater exclusively to hams; however, The University of Twente, Enschede, Netherlands (http://websdr.ewi.utwente.nl:8901/) covers 0.000 to 29.160 MHz unabridged.  The screenshot below shows the tablet/phone version of the U. of Twente site.  There are also two sites on the US East Coast which cover some non-hamband portions of the SW spectrum:  http://na5b.com:8901/ in the Washington, DC area and http://websdr.k3fef.com:8901/ in Milford, Pennsylvania.  The SHORT.WAVE.INFO and WebSDR sites can be directly accessed and queried over the tablet’s browser and a Wi-Fi or cellular connection.

Using the System

In my relentless pursuit to log the Nibi-Nibi Islands, I will load up one of the frequency-time-station listings and start my DX session.  This typically includes a scan of a particular band, checking signals I can receive against the lists.  If my interest peaks on a particular catch (usually a weak one), I will switch the tablet over to a WebSDR site to see how it is being received in Europe or along the East Coast of NA.

In summary, ready access to these Internet resources using a phone or tablet next to the radio has notable advantages:

  • The frequency-time-station listings provide quick, reliable signal identification in most cases.
  • The WebSDR sites confirm that my antennas are doing their job.

Am I done?  I hesitate to stop here.  The process of discovery is a marvelous human experience.  The foregoing are merely starting points.  Other applications might include sunrise-sunset calendars or maps or propagation forecasts.  There are certainly other ways to do all this depending on your druthers.  I know I am erring by omission and neglecting many other good resources.  Let’s hear about yours.
